Current Position： >WDM >Others WDM >OTDR WDM Reflector (1644.5-1655.5nm)
OTDR WDM Reflector (1644.5-1655.5nm)6411194985de3.jpg

OTDR WDM Reflector (1644.5-1655.5nm)

Flyin SC/APC 1644.5nm to 1655.5nm OTDR WDM reflect widely used in FTTX network.

 
Select at least one parameter!! or inquire now

Related Products

Description

Parameters

FeaturesApplications
High reflectance at test wavelength (Over 99.5%)FTTX?network
Based?on?FBG?technology?FTTX?troubleshooting
Easy?to?install
Exceptional?reliability?and?environmental?stability


The production workshop show

Performance Specifications

ParameterSpecification
Wavelength Rang（nm）Pass Band? ? ? ? ? ? ? ?1260~1360&1460~1600&1600~1625
Reflection Band1644.5~1655.5
Insertion Loss (dB)Pass Band @1260-1360
≤1.4
Pass Band @1460-1600≤1.4
Pass Band @1600-1625≤3.4
Reflect Band @1644.5~1655.5≥21
Return Loss（dB）Reflect Band @1260-1360≥35
Reflect Band @1460-1600≥30
Reflect Band @1600~1625≥20
Reflect Band @1644.5~1655.5≤1.0
Polarization Dependent Loss（dB）≤0.3
TDL (dB)≤0.5
Ripple (dB)≤0.5
Maximum Optical Power Handing (dBm)27
Plug Times (Times)500
Input/Output Connectors*SC/APC

*Note:? SC/UPC, LC/UPC and LC/APC type are all available on request.


Absolute Maximum Ratings

Parameters ?

Conditions ?

Specifications ?

Unit

Min.

Max.

Operating ? Temperature

Device ? Not Powered on Heater Element

-20

75

oC

Operating ? Humidity

Non-Condensing ? Environment

0

95

%RH

Storage ? Temperature

Device ? Not Powered on Heater Element

-40

85

oC

Storage ? Humidity

Non-Condensing ? Environment

0

95

%RH
