Description
Parameters
參數/Parameters | Specifications | Unit |
工作波長/Operating Wavelength | 1260 ~ 1620 | nm |
中心波長(λc)/Center Wavelength(λc) | 1471 | nm |
透射通道帶寬/Channel Pass Bandwidth? ? | 1404.5~1417.5 | nm |
透射通道插入損耗/Pass ? Channel Insertion Loss (Com-T) | ≤1.0 | dB |
反射通道插入損耗/Reflect Channel Insertion Loss(Com-Reflect) | ≤0.8 | dB |
平坦度/Ripple | ≤0.3 | dB |
透射通道隔離/Pass Channel Isolation | ≥30 | dB |
反射通道隔離/Reflect Channel Isolation | ≥12 | dB |
方向性/Directivity | ≥40 | dB |
回波損耗/Return Loss | ≥45 | dB |
熱穩定性/Thermal Stability | ≤0.005 | dB/℃ |
熱溫漂/Thermal Stability Drift | ≤5 | pm/℃ |
偏振相關損耗/Polarization Dependent Loss | ≤0.10 | dB |
偏振模色散/Polarization Mode Dispersion | ≤0.10 | ps |
最大光功率/Maximum Power Handing | 300 | mW |
光纖長度/Fiber Length | ≥2 | m |
光纖類型/Fiber Type | 2.0mm LSZH SM | |
工作溫度/Operating Temperature | 0 ~ 70 | ℃ |
儲存溫度/Storage Temperature | -40 ~ 85 | ℃ |
拉伸載荷/Tensile load | 5 | N |
備注/ Notes: 所有插入損耗值都包括連接頭之損耗值。/Insertion Loss tested with connector.
參數/Parameters | Specifications | Unit |
工作波長/Operating Wavelength | 1260 ~ 1620 | nm |
中心波長(λc)/Center Wavelength(λc) | 1471 | nm |
透射通道帶寬/Channel Pass Bandwidth? ? | 1404.5~1417.5 | nm |
透射通道插入損耗/Pass ? Channel Insertion Loss (Com-T) | ≤1.0 | dB |
反射通道插入損耗/Reflect Channel Insertion Loss(Com-Reflect) | ≤0.8 | dB |
平坦度/Ripple | ≤0.3 | dB |
透射通道隔離/Pass Channel Isolation | ≥30 | dB |
反射通道隔離/Reflect Channel Isolation | ≥12 | dB |
方向性/Directivity | ≥40 | dB |
回波損耗/Return Loss | ≥45 | dB |
熱穩定性/Thermal Stability | ≤0.005 | dB/℃ |
熱溫漂/Thermal Stability Drift | ≤5 | pm/℃ |
偏振相關損耗/Polarization Dependent Loss | ≤0.10 | dB |
偏振模色散/Polarization Mode Dispersion | ≤0.10 | ps |
最大光功率/Maximum Power Handing | 300 | mW |
光纖長度/Fiber Length | ≥2 | m |
光纖類型/Fiber Type | 2.0mm LSZH SM | |
工作溫度/Operating Temperature | 0 ~ 70 | ℃ |
儲存溫度/Storage Temperature | -40 ~ 85 | ℃ |
拉伸載荷/Tensile load | 5 | N |
備注/ Notes: 所有插入損耗值都包括連接頭之損耗值。/Insertion Loss tested with connector.
